A familiar protocol for easy execution.
Our AAV Titration ELISA kits use a standard sandwich ELISA method utilizing exclusive AAV antibodies developed using our proprietary immunization scheme.
- Pre-coated microtiter plate with removable single-use test strips.
- AAV standard and sample is incubated on plate.
- Biotinylated detection antibody is added to bind AAV capsids.
- Streptavidin HRP conjugate is added to bind with antibody-AAV complex.
- HRP will then oxidize TMB substrate to produce a color change porportional to AAV capsid titer.
Proprietary monoclonal antibodies developed using enhanced immunization scheme.
Our AAV ELISA kits using recombinant monoclonal antibodies developed using our proprietary immunization scheme that overcomes the weak AAV immunogenicity. This method maintains a remarkable level of consistency as the serum titers within the same group of mice consistently align. Across all AAV serotypes, our technique consistently elevates AAV anti-serum titers, resulting in the production of high- performance monoclonal antibodies.
Browse AAV ELISA Kits
AAV2 Titration ELISA Kit Exhibits Near-Zero Cross-reactivity with AAV3
This graph demonstrates the cross-reactivity analysis of the AAV2 Titration ELISA Kit with AAV3. The data shows a dose-response curve for the AAV2 standard, while the AAV3 standard exhibits minimal reactivity, indicating the kit's high specificity for AAV2 with no cross-reactivity detected for AAV3.
Overview of AAV ELISA Kits
Sandwich ELISA assays are a trusted technique for quantification of adeno-associated virus (AAV) capsid proteins, enabling researchers to determine viral titers with high specificity and sensitivity. KACTUS has developed a portfolio of AAV Titration ELISA kits that are designed to detect and quantify AAV capsid proteins across different AAV serotypes. These kits are broadly applicable in gene therapy research.
Due to the low immunogenicity of AAVs, and its growing role in gene therapy, we have developed a proprietary AAV immunization scheme that produces high affinity anti-AAV monoclonal antibodies. We have extensively validated these ELISA assays to ensure that AAV titers can be accurately and consistently determined. Our AAV ELISA assays can be applied to both preclinical and clinical research, supporting vector production, potency testing, and the development of novel therapeutics. These kits offer high accuracy, reproducibility, and specificity for adeno-associated virus detection.
How the AAV ELISA Kits Work
The assay uses a sandwich ELISA method to analyze samples with varying AAV concentrations. Our kits have a broad linear range to detect viral capsids over a dynamic range. AAV particles are captured using serotype-specific monoclonal antibodies immobilized on an ELISA plate. A biotinylated detection antibody is added that binds to the capsid proteins. Following the addition of TMB, a substrate reaction generates an absorbance signal, which is subsequently analyzed against an 8-point standard curve to determine the concentration of viral particles.
This method is widely validated for research use, providing consistent and reproducible results for AAV vector characterization and quality control. The specificity of the ELISA kit allows for differentiation between intact AAV particles and denatured capsid proteins. The antibodies are also highly serotype-specific, for reliable quantification of specific AAVs.
Product Advantages
Wide Linear Range
Example 8-point standard curve for the AAV9 Titration ELISA Kit.
The quantitative range of this kit is 2.03x107 - 1.30109 capsids/mL.
Batch Consistency
KACTUS AAV9 Titration ELISA kit standard curve tested across two batches.
The standard curve is highly reproducible and exhibits an R²>0.99.
Specificity to intact capsids
The ELISA sandwich assay was used to detect the binding of AAV9 antibodies to intact and denatured AAV9 capsid proteins.
The AAV9 detection antibody does not exhibit binding to denatured AAV9 capsid protein.
Specificity to individual serotypes
The cross-binding of different concentrations of AAV9 antibodies to capsid proteins of other serotypes (AAV2/5/8/9) was detected by indirect ELISA.
The AAV9 titration ELISA kit is highly specific to the AAV9 serotype and does not exhibit cross-reactivity with other AAV serotypes.
High Accuracy
KACTUS AAV9 Titration ELISA kit was used to test the recovery rate of three AAV9 titers (high, medium, and low) in spiked dilution buffer (left) and HEK293 cell lysate (right).
The sample recovery rates of AAV9 samples with different titers detected in the dilution buffer and cell lysate were all between 80% and 120%, indicating that this kit has high accuracy in detecting AAV9 titers.
High Precision
| Sample | Runs | Average (capsids/mL) | Coefficient of Variation (%CV) |
|---|---|---|---|
| 6.5E+08 capsids/mL | n=10 | 6.18E+08 | 2.80% |
| 1.63E+08 capsids/mL | n=10 | 1.92E+08 | 1.90% |
| 2.03E+07 capsids/mL | n=10 | 2.17E+07 | 5.90% |
The same batch of AAV9 test kits were used to test three different titer AAV9 samples (high, medium and low). Each sample was tested 10 times. The average and coefficient of variation (%CV) of these 10 titer tests was calculated.
The %CV for all three sample concentrations (high, medium and low) was less than 10%, indicating that the AAV9 Titration ELISA kit has good intra-batch repeatability.
Frequently Asked Questions
Assay Kit Specifications
Based on our performance validation, KACTUS AAV antibodies specifically recognize intact AAV particles and do not bind to denatured AAV capsids.
The antibodies used in KACTUS AAV Titration ELISA Kits are indeed highly specific to their respective serotypes and do not cross-react with other serotypes. For example, the AAV9 ELISA kit specifically detects AAV9 capsid and will not cross-react with other serotypes such as AAV2, AAV5, AAV6, or AAV8.
The AAV standard consists of clinical-grade empty AAV capsids, the concentration of which has been validated by our in-house methods.
KACTUS AAV Titration ELISA Kits contain the following components: Pre-coated microplate, AAV Standard, Capture Antibody, Detection Antibody, HRP Conjugate, 10X Assay Buffer, 20X Wash Buffer, TMB, and Stop Solution.
All components should be stored at 2-8 °C for up to 1 year.
Assay Kit Usage
KACTUS AAV ELISA kits use sandwich ELISA to determine the titer of AAV capsids in the test sample. The capture monoclonal antibody is pre-coated and treated on a 96-well reaction plate. The AAV standard or sample is added to the pre-coated plate and specifically binds to the capture antibody. The biotinylated detection antibody is then added to the plate to bind the immune complex. Next, the streptavidin HRP conjugate is added to react with the biotin molecules. The addition of TMB results in color changes, the amplitude of which is proportional to the quantity of AAV capsids that specifically bind to the plate. The reaction is stopped with the addition of stop solution and the absorbance is measured at 450nm. The sample capsid titer is calculated from the standard titration curve.
Yes. KACTUS AAV Titration ELISA Kits are provided with one pre-coated microtiter plate containing 12 x 8-well-strips. KACTUS recommends the use of seven serial dilutions of the provided AAV standard (standard curve), two blank controls (negative controls) and 2-3 dilutions of the test samples to ensure a reliable quantification of AAV titers. The standard curve, negative controls, and test samples should be run in duplicate to ensure the most accurate results. For further information, check the datasheet provided with your AAV ELISA kit. If a test sample has two dilutions, and each dilution is run in duplicate, then one kit can be used to quantify 20 samples.
This is not recommended. Components from different batches should not be mixed.
There are many ways to fit the standard curve, such as linear fitting, polynomial fitting, four-parameter fitting, etc. You should select the most appropriate fitting method based on your experimental needs. If you require assistance with curve fitting or troubleshooting, please contact support@kactusbio.us.
We recommend you run a new standard curve on each plate. Although the procedure of ELISA experiments is the same, each individual plate will show variation.
KACTUS AAV Titration ELISA Kit is for research use only and cannot be used for clinical diagnosis or patient treatment.
