Product Description |
Recombinant Biotinylated Human PD-L1/B7-H1 is expressed from HEK293 with His tag and Avi tag at the C-Terminus.It contains Phe19-Arg238. |
Product Background |
B7-H1, also known as PD-L1 and CD274, is an approximately 65 kDa transmembrane glycoprotein in the B7 family of immune regulatory molecules. PD-L1 has been identified as the ligand for the immunoinhibitory receptor programmed death-1(PD1/PDCD1) and has been demonstrated to play a role in the regulation of immune responses and peripheral tolerance. |
Product Category |
Recombinant Protein |
Protein |
PD-L1/B7-H1 |
Synonyms |
CD274; PDL1; PD-L1; PD-L1B7 homolog 1;B7-H; B7H1; B7-H1; PDCD1L1; PDCD1LG1 |
Accession |
|
Species |
Human |
Biotinylated |
yes |
Amino Acid Range |
Phe19-Arg238 |
Molecular Weight |
The protein has a predicted MW of 28.1 kDa. Due to glycosylation, the protein migrates to 35-45 kDa based on Bis-Tris PAGE result. |
Activity |
Immobilized Anti-PD-L1 Antibody, hFc Tag at 0.5ug/ml (100ul/Well) on the plate. Dose response curve for Biotinylated Human PD-L1, His Tag with the EC50 of 9.4ng/ml determined by ELISA. See testing image for detail. |
Product Tag |
C-His-Avi |
Expression System |
HEK293 |
Purity |
> 95% as determined by Bis-Tris PAGE;> 95% as determined by HPLC |
Endotoxin |
Less than 1EU per ug by the LAL method. |
Form |
Lyophilized |
Shipping |
Shipped at ambient temperature. |
Formulation |
Lyophilized from 0.22um filtered solution in PBS (pH 7.4). Normally 8% trehalose is added as protectant before lyophilization. |
Reconstitution |
Centrifuge the tube before opening. Reconstituting to a concentration more than 100 ug/ml is recommended. Dissolve the lyophilized protein in distilled water. |
Stability And Storage |
Reconstituted protein stable at -80°C for 12 months, 4°C for 1 week. Use a manual defrost freezer and avoid repeated freeze-thaw cycles. |
|
|
Immobilized Anti-PD-L1 Antibody, hFc Tag at 0.5ug/ml (100ul/Well) on the plate. Dose response curve for Biotinylated Human PD-L1, His Tag with the EC50 of 9.4ng/ml determined by ELISA. |
|
|
Immobilized Biotinylated Human PD-L1, His Tag at 1ug/ml (100ul/well) on the streptavidin precoated plate (5ug/ml). Dose response curve for Human PD-1, hFc Tag with the EC50 of 5.2ng/ml determined by ELISA (QC Test). |
|
|
Biotinylated Human PD-L1 on Bis-Tris PAGE under reduced condition. The purity is greater than 95%. |
|
|
The purity of Biotinylated Human PD-L1 is greater than 95% as determined by SEC-HPLC. |
