Graph showing the Human B7-H5, His Tag ELISA with a 0.05 µg concentration of Human B7-H5 His Tag per well. The x-axis represents the log concentration of Anti-B7-H5 Antibody, hFc Tag (µg/ml), and the y-axis shows the mean absorbance (OD450). The curve illustrates a dose-dependent increase in absorbance.
Human B7-H5/Gi24/VISTA Protein (BH7-HM175)
Human B7-H5/Gi24/VISTA Protein (BH7-HM175)
  • Express System: HEK293
  • Product Tag: C-His
  • Purity: > 95% as determined by Bis-Tris PAGE;> 95% as determined by HPLC
  • Activity: Immobilized Human B7-H5, His Tag at 0.5ug/ml (100ul/well) on the plate. Dose response curve for Anti-B7-H5 Antibody, hFc Tag with the EC50 of 2.6ng/ml determined by ELISA. See testing image for detail.
  • Amino Acid Range: Phe33-Ala194
Catalog #BH7-HM175
Regular price $264.00
/
Size

Order now, ships by:

Human B7-H5/Gi24/VISTA Protein (BH7-HM175) Summary

Product Description

Recombinant Human B7-H5/Gi24/VISTA Protein is expressed from HEK293 with His tag at the C-Terminus.It contains Phe33-Ala194.

Product Background

B7-H5, also known as VISTA , B7H5, Dies1, SISP1 and C10orf54, is a 55-65 kDa member of the Ig superfamily. It is a transmembrane molecule expressed in bone, on embryonic stem cells (ESCs), and on tumor cell surfaces.

Product Category

Recombinant Protein / Antibody discovery / Immune checkpoint proteins

Human B7-H5/Gi24/VISTA Protein (BH7-HM175) Specifications/Details

Protein
B7-H5/Gi24/VISTA
Synonyms
B7H5; B7-H5; VISTA; VSIR ; PD1H; PD-1H; 4632428N05Rik; C10orf54; Dies1; Gi24; PP2135; SISP1
Accession
Species
Human
Biotinylated
no
Amino Acid Range
Phe33-Ala194
Molecular Weight
The protein has a predicted MW of 19 kDa. Due to glycosylation, the protein migrates to 32-70 kDa based on Bis-Tris PAGE result.
Activity
Immobilized Human B7-H5, His Tag at 0.5ug/ml (100ul/well) on the plate. Dose response curve for Anti-B7-H5 Antibody, hFc Tag with the EC50 of 2.6ng/ml determined by ELISA. See testing image for detail.

Product Tag

C-His
Expression System
HEK293
Purity
> 95% as determined by Bis-Tris PAGE;> 95% as determined by HPLC
Endotoxin
Less than 1 EU per ug by the LAL method.
Form
Lyophilized
Shipping
Shipped at ambient temperature.
Formulation
Lyophilized from 0.22um filtered solution in PBS (pH 7.4). Normally 8% trehalose is added as protectant before lyophilization.
Reconstitution
Dissolve the lyophilized protein in distilled water. It is recommended to resuspend at 0.5 mg/mL if the lyophilized powder is 100 ug or less, at 1mg/ml for 500ug or 1mg lyophilized powder. Do not mix by vortex or vigorous shaking.
Stability And Storage
-20 to -80°C for 12 months as supplied from date of receipt.;-80°C for 3 months after reconstitution.;Recommend to aliquot the protein into smaller quantities for optimal storage. Please minimize freeze-thaw cycles.
Immobilized Human B7-H5, His Tag at 0.5ug/ml (100ul/well) on the plate. Dose response curve for Anti-B7-H5 Antibody, hFc Tag with the EC50 of 2.6ng/ml determined by ELISA. Immobilized Human B7-H5, His Tag at 0.5ug/ml (100ul/well) on the plate. Dose response curve for Anti-B7-H5 Antibody, hFc Tag with the EC50 of 2.6ng/ml determined by ELISA.
Human B7-H5 on Bis-Tris PAGE under reduced condition. The purity is greater than 95%. Human B7-H5 on Bis-Tris PAGE under reduced condition. The purity is greater than 95%.
The purity of Human B7-H5 is greater than 95% as determined by SEC-HPLC. The purity of Human B7-H5 is greater than 95% as determined by SEC-HPLC.
